Waterfowl-Works is proud to bring you the
"ORIGINAL" Lake Erie layout boat plans. We have
purchased the rights to these plans and therefore
are proud to bring them back to the market. hundreds
of these boats have been built using these perfected
plans. Very simple and easy to follow detailed
directions. This is the alternative to high shipping
costs on fiberglass manufactured layout boats and
also a great summer project for the waterfowling
family. We have changed nothing and added a few
options that we feel only make them better. We offer
plans for both 1 man and 2 man layout boats.
WHAT IS
INCLUDED IN THE PLANS
*Full sized templates of each
part that you trace onto your wood stock parts.
*Full written instructions of the
step-by-step procedures.
*A complete material list.
*Instructions on how to make and
install the skirting as well as hardware options.
*Detailed drawings with easy to
read views, part numbers, plywood layout.
*Tips and techniques to provide
savings and comfort options.
*live support.
WHAT
YOU NEED TO PROVIDE
*Lumber, plywood and
fasteners per the materials list.
*Glue, paint, and skirting
materials.
*Epoxy or fiberglass resin
and cloth.
*Basic power and hand tools.
1 MAN LAYOUT BOAT PLANS
These plans will guide you
through the construction of a boat
that is approximately 10ft long
and 48" wide. It has options for
the depth of the box and towing and
non towing hulls.
The approximate finished weight
of the boat will be 125-150lbs.
2 MAN
LAYOUT BOAT PLANS
These plans will guide
you through the construction of a boat that
is approximately 12ft long and 78" wide. It
has options for the depth of the box and
towing and non towing hulls. The approximate
Finished weight of the boat will be
225-250lbs.
Price
$69.99
Building the Erie Layout
boat Video
This video is over 2 hours
of hands on how to build the Erie layout
boat. Shows you step by step from material
selections to the final touches of
installing the spray curtain. A must have
for those who need a little extra confidence
on building there own layout boat.
